Horizontal plow ( PLOUGHSHARE) mixer is a very effective solution for ultra fast mixing of dry powders,granules or liquids with or without adding liquid. It is used in the chemical, pharmaceutical (vitamins, vitaminmixtures) and the food industry (ice cream, sugar, milk powder, spices, flour, powders, pastes, granules, …).A complete set of high-speed blade enhances the mixing process.
- Vitamin mixture
- Dry ice cream
- Milk powder and whey powder
Plow mixer ( PLOUGHSHARE) is a closed cylindrical tank, which is equipped with a high speed stirrer (blade) in the form of a plow. Extremely high energymixing creates a whirlpool effect, which gives rise to a homogeneous mixture in a very short time. In addition, this form of highly effective agitator bladesprovides breaking up the lumps. The plum mixer is very powerful and effective, and achieves excellent results constantly stirring after 20 seconds.
- different capacity
- optional material (AISI 304 or AISI 316)
- different types of mixers
- High sped mixing
- Quality materials
- High efficiency
- Quality construction
- Easy cleaning and maintenance, quick access to all parts
- Short period of mixing
- Optional capacity
- Easy to use
Controling is ensured by automatic control (PLC), which is designed for more complex machinery, equipment and production lines, where it is necessary to record the temperature, temperature sensing, signaling limitparameters, take multiple values, automatic dosing, level control, time setting, monitoring etc.
|Model||Volume min||Volume max||material||stirring time -min|
|Horizontal PLOUGHSHARE mixer NP-0075||9||65||AISI 304, AISI 316||1-4|
|Horizontal PLOUGHSHARE mixer NP-0075||510||750||710|
